Waste Water Disposal :

Wastewater Disposal for (Sobk Al-Dahak,Kafr Al-Khadra,Qalta Al kobra, Samman, Feesha Al Soghra, Kafr Manawahla, Abu Snaita and Bahnay,Koam El Dab'e, Meet Al Beida,El-Khadra) - El Bagoor - Menoufya

Project value & Date:

  • The Value of contract is 212.453766 Million EGP
  • The Contract Date 11/24/2001
  • The End Date 6/30/2023

Project Description:

 Gravity Networks:
 * VC piplines from 12" to 24" dia. with total length 25 km. +UPVC  pipelines of dia 7": 10" and length 3 km
 *UPVC pipelines dia 150 :400 and length 1.6km
*Pressurized pipelines in Sobk Al-Dahak & Kafr El-Khadra  from PE pipelines dia 200:300 mm and length 2.7 km
 Pump Stations:
 * Three Secondary in Sobk Al-Dahak
 * Two Main in Kafr Al-Khadra . Discharge from  600:30000m3/day
* one wastwater Treatment plants in Sobk Al-Dahak & Kafr El-Khadra of discharge 6000 m3/day each
- 2 pipe jacking crossings cultivate RC  of dia 1500,1800  mm to pass DI  of dia 150 :600 mm with length 72 m .
 -6 open cut excavations  crossing DI of dia 250 :600 and length 318.4 m
