Société Egyptienne D’entreprises

Waste Water Disposal :

Wastewater Disposal for EL Mounshaa and Awlad Hamza

Project value & Date:

  • The Value of contract is 171.475247 Million EGP
  • The Contract Date 1/5/2002
  • The End Date 5/8/2019

Project Description:

* Gravity Networks:-
     - V.C. Pipelines of 7" : 32" dia & 55.28 km  length.
     - R.C pipelines of 1000 : 1300 mm dia and 2.5 km length.
* House connections:
PVC pipelines 150 mm dia.,4 km length.
* Pressurized Pipelines:-
     - Dual prestressed R.C Pipelines of 800 mm dia , 10 km length.
     - GRP pipelines of 400 : 700 mm dia., 12 km length.
     - Ductile Cast Iron pipe line ( D.I ) of 300 mm dia., 0.22 km length.
 -PE pipeline of dia 400 mm and length 0.895 km
*Crossings :(pipe jacking type )
 * Under Rail way and 2 canals behind cairo to luxor Rail way  culvert of 3200mm dia. and 60 m length to pass P.R.C pipeline of 1300 mm dia .
 * Under Nagah Hamady canal culvert of 3.2 m dia. and 60 m length to pass DI  double lines 400, 700 mm dia.
* Under Nagah Hamady canal in front pump station no 1  culvert of 1800 mm dia. , 60 m length to pass DI pipeline of 300 mm dia.
* Open Cut Excavation
- Zarzora canal , length of 90 m.
- El Hakmy canal  20 m length (pipeline of 500mm dia.)
- El bayad canal 20 m length (pipeline of 700 mm dia.)
* crossing under  el kwamel discharge with length 105 m to pass pipeline of dia 800 mm and dia of cultivate 3.2 m
*crossing el bayad river ta pass 700 mm pipeline with length 25 m
 *crossing el mror river of dia 700 mm and length 25 m
*crossing el bayad river to pass 400 mm pipeline to pressurized pipeline  800 mm
* Pump Stations:
     - Three pump stations at El Monshaa City.
- Main P.S no. 3 discharge of 422 L/SEC .dia 14 m &height 14 m
 - Secondary P.S No. 2 , discharge of 310 L/SEC. Dia 12 m &height 13 m
 - Secondary P.S No. 1 , discharge of 70 L/SEC. Dia 5 m & height 10 m
  - Three Pump stations at Awlad Hamza
   - Main P.S No. 3 ,discharge of 880 L/SEC.dia 16 m and height 15 m
    - Secondary P.S No 2 discharge of 200 L/SEC.dia 10 m & height 12 m .
    - Secondary P.S No 1 , discharge of 100 L/SEC.  Dia 8 m & height 11 m
*Wastewater Treatment Plant 30000 m3/day discharge ( Oxidation Basins)
