Project Description:
* Potable water networks:
- D.I pipelines of 400 : 1000 mm dia., & 8.336 km total length.
- UPVC pipelines of 100 : 250 mm & 56.997 km total length.
* Irrigation networks:
- D.I pipelines of 300 : 500 mm dia., & 7.673 km total length.
- uPVC pipelines of 100 : 250 mm dia. & 41.193 km total length.
* Wastewater networks:
-V.C pipelines of 200 : 500 mm dia. & 43.663 km total length.
- Precast R.C pipelines of 700 : 1200 mm dia. & 6.963 km total length.
* D.I Pressurized pipeline of 900 mm dia. & 10 km total length.
* Road works in new Kena city:
*crossings :
-crossing type under railway and qena safaga road (to pass pressurized pipeline) DI with dia 2500 mm and length 170 m
- crossing type under under railway of al flnkat factory ( to pass Potable water pipeline ) DI with dia 2000 mm with length 50m
- crossing type under railway of al flenkat factory( to pass wastewater pipeline ) with dia 2500 mm an d length 50 m
- crossing type under el flenkat factory railway( to pass pressurized pipeline) with dia 2000 and 50 m length
