Project Description:
Gravity Networks :
* V.C. pipelines of 7" : 24" dia. and 44.7 km total length.
* Ductile cast iron pipelines of 200 : 500 mm dia. and 8 km total length and 9 bar working pressure
Crossings :
* Hydraulic pipe jacking for Four Culverts by R.C. pipelines as the following :
* Under EL-Kourashia Canal ( 1500 mm dia. & 37.5 m length ) to pass D.I main force pipeline of 300 mm dia. .
* Under Bahr Shibeen (2250mm dia. & 65 m length ) to pass D.I main force pipeline of 400 mm dia.
* Under Bahr Shibeen for double line (2250 mm dia. & 67 m length ) to pass pair D.I main force pipeline of 200 & 300 mm dia. .
* Under Shershaba Canal &the Railway ( 2000 mm dia. & 80 m length ) to pass D.I main force pipeline of 500 mm dia. .
Open Cut Excavation Crossings
* Under EL -Santa canal for D.I gravity pipe line of 400 mm and 30 m length without outside casing.
Pump Stations :
Five pump stations of 20 to 60 L/sec discharge.
* Pump station of 20 L /sec discharge , 8 m dia. And 9 m height.
* Pump station of 60 L /sec discharge, 10 m dia. And 12 m height.
* Pump station of 30 L /sec discharge , 8 m dia. And 11 m height.
* Pump station of 50 L /sec discharge , 9 m dia. And 12 m height.
* Pump station of 30 L /sec discharge , 8 m dia. And 11 m height.
completion works:
* Pump stations nos (6 &7)
